Before placing your custom ring order, consult the images and explanations below to better understand the required dimensions. This guide will help you identify and measure key parts such as Piston Diameter, Gasket Height, and detailed specifications for the Top and Bottom Side Steps including I/D, O/D, Height, and Width.
Make sure to refer to the appropriate diagram based on the ring type you’re interested in (Flat, L-Type, or T-Type), so you can enter accurate values in your order.
